Overview:

OLS75 power supply/charger converts 115VAC, 60Hz or 230VAC, 50Hz input, into a 12VDC or 24VDC @ 2.5 amps

of continuous supply current (see specifications). This general purpose power supply has a wide range of application for

access control and security system accessories that require additional power.

Specifications:

Voltage Output Selection Table:

Output VDC Switch Position Max. Load DC

12VDC SW 1 - Closed 2.5 amp

24VDC SW1 - Open 2.5 amp

Installation Instructions:

The OLS75 should be installed in accordance with The National Electrical Code and all applicable Local Regulations.

1. Mount the OLS75 in the desired location/enclosure.

2. Slide [Power ON/OFF] switch to OFF position.

3. Set the OLS75 to the desired DC output voltage via SW1 (Voltage Output Selection Table).

4. Connect AC power to the terminals marked [L & N], connect ground to the terminal marked [G].

Use 18 AWG or larger for all power connections (Battery, DC output).

Use 22 AWG to 18 AWG for power-limited circuits (AC Fail/Low Battery reporting).

5. Slide [Power ON/OFF] switch to ON position.

6. Measure output voltage before connecting devices. This helps avoiding potential damage.

7. Slide [Power ON/OFF] switch to OFF position.

8. Connect devices to be powered to the terminals marked [– DC +].

9. When the use of stand-by batteries is desired, they must be lead acid or gel type.

Connect battery to the terminals marked [-- BAT +] (battery leads included).

Use two (2) 12VDC batteries connected in series for 24VDC operation.

10. When batteries are not used, a loss of AC will result in the loss of output voltage.

11. Connect appropriate signaling notification devices to AC Fail & Low battery supervisory

relay outputs marked [NC, C, NO].

12. Slide [Power ON/OFF] switch to ON position.

OLS75 - Offline Power Supply/Charger

Input:

• Universalinput115VAC,50/60Hz, 0.95 amp

or 230VAC, 50/60Hz, 0.6 amp.

Output:

• 12VDC or 24VDC selectable output.

•2.5ampcontinuoussupplycurrent.

• Filteredandelectronicallyregulatedoutput.

• Shortcircuitandthermaloverloadprotection.

Battery Backup:

• Built-inchargerforsealedleadacidorgeltypebatteries.

• Automaticswitchovertostand-bybatterywhenACfails.

• Maximumchargecurrent0.5amp.

• Batteryleadsincluded.

Supervision:

• ACfailsupervision(form“C”contacts).

• Lowbatterysupervision(form“C”contacts).

Visual Indicators:

• ACinputandDCoutputLEDindicators.

Electrical:

• Operatingtemperature:---20ºCto49ºCambient.

• BTU/Hr.:12VDC:15.35BTU/Hr.24VDC:30.7BTU/Hr.

• SystemACinputVArequirement:

 115VAC:109.25VA.230VAC:138VA.

Features:

• PowerON/OFFswitch.

Mechanical:

• BoardDimensions(approx.LxWxH):

 7.25”x4.5”x1.75”(183.9mmx114.52mmx44.45mm)

1 2

OFF ON 2

Summary of Contents

Page 1

Overview:OLS75 power supply/charger converts 115VAC, 60Hz or 230VAC, 50Hz input, into a 12VDC or 24VDC @ 2.5 amps of continuous supply current (see sp

Page 2 - OFF ON

LED Diagnostics:Red (DC) Green (AC) Power Supply StatusON ON Normal operating condition.ON OFF Loss of AC, Stand-by battery supplying power.OFF ON No
